Highland Park Ford Plant
Ford operates its moving Model T chassis-assembly line at Highland Park
View full image ↗ How was this image made?
The creative brief sent to the image model. These are instructions, not a record of what actually happened.
Original prompt & settings (JSON) ↗On 7 October, 140 people stood along 150 feet of factory floor and finished 435 chassis before the nine-hour shift ended.
7 October 1913 at Highland Park
At Ford's Highland Park plant in Michigan on 7 October 1913, 140 assemblers were stationed along a 150-foot moving chassis-assembly line, with components placed at appropriate points beside them.
During a nine-hour day the line completed 435 Model T chassis.
The recorded labour content was 2 hours 57 minutes of one worker's time per chassis, against roughly 12 hours 28 minutes under the earlier stationary arrangement.
Still being improvised
This was a chassis line, not the sudden mechanisation of the whole factory; Ford had already introduced moving work for magnetos and other components earlier in 1913.
The setup kept changing. By 1 December the line ran 300 feet with 177 assemblers, producing 606 chassis in nine hours at about 2 hours 38 minutes of labour each, and an endless-chain drive was installed on 14 January 1914.
The reported hours are labour-hours per chassis, not elapsed clock time from bare frame to finished automobile.
Which date, and whose invention
October 7 is supported by Horace Lucien Arnold and Fay Leone Faurote's detailed 1915 technical account and by several later histories, but other institutional histories give 1 October, October generally, or 1 December as the debut.
The disagreement reflects an incremental process: component lines, a rope-and-windlass chassis experiment, a larger manually advanced line and a powered endless-chain line all appeared at different times.
A group of managers, engineers and workers developed the system; it should not be attributed to Henry Ford acting alone.
Sources
Researched 23 Aug 2026 7 sources 2 audit passes Date disputed
How this was checked
Researched from the web into a fact sheet, rewritten from that sheet, then audited against it by a different model. How the pipeline works →
Date disputed. Sources disagree about when this happened.
What the sources leave uncertain
- October 7 is supported by the detailed 1915 technical account and several later histories, but other institutional histories give October 1, October generally or December 1 as the debut.
- The disagreement reflects an incremental process: component lines, a rope-and-windlass chassis experiment, a larger manually advanced line and a powered endless-chain line appeared at different times.
- The title-as-listed begins “December 1,” while its slug and listed date say October 7. The December 1 figures belong to a later configuration.
- The reported hours are labor-hours per chassis, not necessarily elapsed clock time from an empty frame to a completed automobile.
Checked against
- Ford Methods and the Ford Shops — 1915 scan
- Ford Methods and the Ford Shops — Library of Congress catalog record
- Ford Implements the Moving Assembly Line — Library of Congress
- Highland Park — Ford Motor Company
- Ford company timeline
- Ford’s Model T: A Car for the Great Multitude — The Henry Ford
- 1924 Ford sales brochure — The Henry Ford
